PTAC Thermostats
Technical information
WIRELESS THERMOSTAT SPECIFICATIONS
Product Dimensions
3.4" x 3.4" x 0.9" (8.6cm x 8.6cm x 2.3cm)
Mounting Type
Surface Mount
HVAC System
PTAC/VTAC/Heat Pump
Power Requirements
Alkaline Batteries (4 AAA)
Display
1.3" (128 x 64) OLED
Number of Keys
4 Touch Keys
LED Indicator
1, Red
Temperature Range
33-99°F (+/-1°F) / 1-37°C (+/-0.5°C)
Occupancy Sensing
Maximum Detection Distance: 9m, Maximum Detection Angle: 120°
Diagnostic Connection
USB-Type C
RF Interface
ZigBee 3.0, Frequency Band: 2.4GHZ
APP System
Android 8.0 or higher
Battery Life
24 Months
Approvals
UL62368-1; FCC Part 15B; Part 15.247; Part 15.249
CONTROLLER CARD SPECIFICATIONS
Product Dimensions
3.9”x2.4”x1” (10cm x 6.0cm x 2.4cm)
Mounting Type
Double-sided tape
HVAC System
PTAC/VTAC/Heat Pump
Power Requirements
Input 24V AC ~50/60Hz 0.5A with “C” common wire
Recommended Wire
24 Gauge
Number of Keys
1 Pair Button
LED Indicator
1, Dual Color
Outputs
Output 0.5A MAX @24VAC
RF Interface
ZigBee 3.0, Frequency Band: 2.4GHZ
APP System
Android 8.0 or higher
Approvals
UL60730-1;UL60730-2-9; FCC Part 15B; Part 15.247; Part 15.249
CARTON DIMENSIONS
Quantity
10
Dimensions
14.01" x 8.15" x 8.54" (35.6cm x 20.7cm x 21.7cm)
Weight
10.8lbs (4,900g)
CONTROLLER CARD INSTALLATION - WIRING TABLE
| WIRE COLOR | CONVENTIONAL SYSTEM | HEAT PUMP SYSTEM |
|---|---|---|
| Black | C - 24VAC Common Wire | C - 24VAC Common Wire |
| Red | R - 24VAC Power | R - 24VAC Power |
| Yellow | Y1 or W3 - 1ST Stage of Compressor Relay/3RD Stage of Heat Relay | Y1 - 1ST Stage of Compressor Relay |
| White | W1 - 1ST Stage of Heat Relay | W1 or Y2 - Aux Heat/1ST Stage of Heat/2ND Stage of Compressor Relay |
| Orange | O/B or W2 - Not Used/2ND Stage of Heat Relay | O/B - Changeover Valve Relay |
| Green | GH - Fan Relay, High | GH - Fan Relay, High |
| Purple | GL - Fan Relay, Low | GL - Fan Relay, Low |
| Brown | AUX - Occupancy Out | AUX or E - Occupancy Out/Emergency Heat |
